KF Solar Wall-Mounted LiFePO4 Battery 5kWh 51.2V Home Energy Storage System
Product Overview
The KF Solar Wall-Mounted LiFePO4 Battery is a high-performance residential energy storage solution designed for solar power systems. Built with advanced Lithium Iron Phosphate (LiFePO4) technology, this battery provides reliable backup power, long service life, and excellent safety performance. It is ideal for home solar storage, hybrid energy systems, and off-grid applications.
Key Features
- Advanced LiFePO4 Battery Technology
- 51.2V Nominal Voltage
- 5kWh–10kWh Energy Storage Options
- Wall-Mounted Space-Saving Design
- Long Service Life of Up to 6000 Cycles
- Hybrid Grid Compatible
- High Safety Solid-State Battery Structure
- Wide Operating Temperature Range
- Suitable for Residential Solar Energy Storage Systems
- 10-Year Warranty
- OEM & ODM Customization Available
Technical Specifications
| Item | Specification |
|---|---|
| Product Name | Lithium Iron Phosphate (LiFePO4) Battery |
| Brand | KF Solar |
| Model Number | NO.789 |
| Battery Chemistry | LiFePO4 (Lithium Iron Phosphate) |
| Battery Type | Solid-State Rechargeable Lithium Battery |
| Nominal Voltage | 51.2V |
| Energy Capacity | 5kWh – 10kWh |
| System Voltage | 51.2V |
| System Type | Wall-Mounted |
| Grid Connection | Hybrid Grid |
| Cycle Life | 6000 Cycles |
| Maximum Cell Quantity | 32 Cells |
| OEM / ODM | Acceptable |
| Warranty | 10 Years |
Physical Specifications
| Item | Specification |
|---|---|
| Dimensions (L × W × H) | 650 × 260 × 1805 mm |
| Installation Type | Wall-Mounted |
| Color | White |
Environmental Specifications
| Item | Specification |
|---|---|
| Operating Temperature | -25°C to +60°C |
| Place of Origin | Guangdong, China |
Applications
- Residential Solar Energy Storage Systems
- Home Backup Power Systems
- Hybrid Solar Installations
- Renewable Energy Storage Projects
- Off-Grid Residential Power Solutions
- Emergency Backup Power Supply
- Small Commercial Energy Storage Applications
Product Advantages
Long Lifespan
The LiFePO4 chemistry delivers up to 6000 charge-discharge cycles, significantly reducing replacement costs over the product lifetime.
High Safety Performance
Solid-state battery technology provides enhanced thermal stability and operational safety compared with conventional lithium batteries.
Space-Saving Installation
The wall-mounted design minimizes floor space requirements and allows flexible installation in utility rooms, garages, and energy storage areas.
Reliable Energy Backup
Provides stable and continuous power during grid outages while maximizing solar self-consumption.
Wide Temperature Adaptability
Operates reliably in temperatures ranging from -25°C to 60°C, making it suitable for various climate conditions.
Package Contents
- Wall-Mounted LiFePO4 Battery Unit
- Integrated Battery Management System (BMS)
- Mounting Bracket Set
- Communication Interface Components
- Installation Accessories
- User Manual
Customization Services
- OEM Manufacturing
- ODM Product Development
- Capacity Customization
- Branding Customization
- Label & Packaging Customization
- Project-Based Energy Storage Solutions
